BCS 770HY Two Wheel Tractor
- Regular price Price ex VAT: £4,815.00
- Regular price Price inc VAT: £4,815.00
The BCS 770HY is the newest addition to the BCS Two Wheel Tractor range and features a hydrostatic drive that can be continuously adjusted with two speed ranges.
See the compatibility table for details.
Why the BCS 770HY Two Wheel Tractor?
Like all BCS machines, the BCS 770HY is very simple to operate and features the patented BCS PowerSafe® clutch that stops both the drive and implement when you let go of the operator presence lever. It does this without stopping the engine and in our opinion this makes the BCS Two Wheel Tractor the safest machine available in the world today.
The 770HY is the only machine in the range that has a hydrostatic drive. The ergonomic control lever is conveniently located on the handlebar ensuring maximum operator comfort during use, especially when the application involves many direction changes.
The BCS 770HY is also fitted with a locking differential and steering brakes for complete operator control, whilst large 5.00 x 10 wheels give you the traction you need whether you are on wet mud or icy pavements.
The range of implements available, coupled with the power of the BCS 770HY, will enable you to undertake a wide range of work. Rotavate in spring, cut grass in summer, chip wood in autumn, and clear snow in the winter.
If multiple attachments are in use the optional implement quick coupling is useful.
Implements and Attachments
The BCS Two Wheel Tractors are supplied as power units only so that you can choose the implements required.
See the IMPLEMENTS tab above for more details.
Download the comparison table to easily see the features of all power units in the BCS Two Wheel Tractor range.
BCS 770HY Engine
| Model | Honda GX390 | Yanmar LN100 |
| Fuel | Petrol | Diesel |
| Net Power Output | 11.7hp / 8.7kW @3600rpm |
9.0hp / 6.7kW @3600rpm |
| Starting | Recoil or Electric | Recoil or Electric |
| Fuel Tank Capacity | 6.1L | 5.5L |
| Fuel Consumption | 3.5L per hour @3600rpm |
2.1L per hour @3600rpm |
BCS 770HY Power Unit
| No of Speeds | 2 ranges - slow & fast | |
| Speeds | Slow: | Up to 4.3km per hour |
| Fast: | Up to 6.4km per hour | |
| Brakes | Steering brakes | |
| Parking brake | ||
| Differential | Locking differential | |
| Wheels | 5.00 x 10 agricultural | |
| Weight | Honda GX390: | 138kg |
| Honda GX390 (electric): | 142kg | |
| Yanmar LN100: | 158kg | |
| Yanmar LN100 (electric): | 166kg | |
| Dimensions | Length: | 200cm |
| Width: | 75cm (at handlebars) | |
| 58cm (at wheels) | ||
| Height: | 120cm | |
| Warranty | Domestic use: | 3 years |
| Commercial use: | 2 years | |
Parts Diagrams
 |
BCS 770HY PowerSafe® Two Wheel Tractor Diagram |
Operating Manuals
|
BCS 770HY PowerSafe® Two Wheel Tractor Instructions |
 |
Original BCS 770HY PowerSafe® Two Wheel Tractor Owner's Manual |
Technical Bulletins
|
BCS PowerSafe® OPC Cable Adjustment |
|
BCS PowerSafe® PTO Gear Changes |
|
How to Remove BCS Gearbox End Cover |
|
BCS Handlebar Upgrade Instructions |
- Features
-
Why the BCS 770HY Two Wheel Tractor?
Like all BCS machines, the BCS 770HY is very simple to operate and features the patented BCS PowerSafe® clutch that stops both the drive and implement when you let go of the operator presence lever. It does this without stopping the engine and in our opinion this makes the BCS Two Wheel Tractor the safest machine available in the world today.The 770HY is the only machine in the range that has a hydrostatic drive. The ergonomic control lever is conveniently located on the handlebar ensuring maximum operator comfort during use, especially when the application involves many direction changes.
The BCS 770HY is also fitted with a locking differential and steering brakes for complete operator control, whilst large 5.00 x 10 wheels give you the traction you need whether you are on wet mud or icy pavements.
The range of implements available, coupled with the power of the BCS 770HY, will enable you to undertake a wide range of work. Rotavate in spring, cut grass in summer, chip wood in autumn, and clear snow in the winter.
If multiple attachments are in use the optional implement quick coupling is useful.
Implements and Attachments
The BCS Two Wheel Tractors are supplied as power units only so that you can choose the implements required.
See the IMPLEMENTS tab above for more details.
Download the comparison table to easily see the features of all power units in the BCS Two Wheel Tractor range.
- SPECIFICATION
-
BCS 770HY EngineModel Honda GX390 Yanmar LN100 Fuel Petrol Diesel Net Power Output 11.7hp / 8.7kW
@3600rpm9.0hp / 6.7kW
@3600rpmStarting Recoil or Electric Recoil or Electric Fuel Tank Capacity 6.1L 5.5L Fuel Consumption 3.5L per hour
@3600rpm2.1L per hour
@3600rpm
BCS 770HY Power UnitNo of Speeds 2 ranges - slow & fast Speeds Slow: Up to 4.3km per hour Fast: Up to 6.4km per hour Brakes Steering brakes Parking brake Differential Locking differential Wheels 5.00 x 10 agricultural Weight Honda GX390: 138kg Honda GX390 (electric): 142kg Yanmar LN100: 158kg Yanmar LN100 (electric): 166kg Dimensions Length: 200cm Width: 75cm (at handlebars) 58cm (at wheels) Height: 120cm Warranty Domestic use: 3 years Commercial use: 2 years
- IMPLEMENTS
-
- VIDEOS
-
- DOWNLOADS
-
Parts Diagrams
BCS 770HY PowerSafe® Two Wheel Tractor Diagram Operating Manuals
BCS 770HY PowerSafe® Two Wheel Tractor Instructions Original BCS 770HY PowerSafe® Two Wheel Tractor Owner's Manual Technical Bulletins
BCS PowerSafe® OPC Cable Adjustment BCS PowerSafe® PTO Gear Changes How to Remove BCS Gearbox End Cover BCS Handlebar Upgrade Instructions
